High Transmissions Polycrystalline Solar Panel For Camping , Travel
, Adventure
Polycrystalline Solar Panel Features:
1. Widely used for camping , travel, adventure and other fields of
outdoors and charge for DC 12v/24v/48v
battery.Included controller, cable, alligator clip, connectors,
protection conners and strong supporting leg
single bag.
2. Providing special design(OEM accepted).
3. Module efficiency : UP TO 16%
4. Warranty : guaranteed 5 years material and workmanship
5. Excellent performance under low light conditions
6. Load test: module certified to wind and snow loads
7. Anti-reflective,hydrophobic layer with light absorption and
minimal surface dust
| Type | M325 | M320 | M315 | M310 | 305 | M300 | M295 | M290 | M285 | M280 |
| Wattage(W) | 325 | 320 | 315 | 310 | 305 | 300 | 295 | 290 | 285 | 280 |
| Open Circuit Voltage(V) | 45.30 | 45.20 | 45.10 | 45 | 44.9 | 44.8 | 44.6 | 44.5 | 44.4 | 44.2 |
| Short Circuit Current(I) | 8.87 | 8.79 | 8.71 | 8.97 | 8.87 | 8.8 | 8.73 | 8.67 | 8.6 | 8.49 |
| Maximum Power Voltage(V) | 37.00 | 36.80 | 36.60 | 36.4 | 36.2 | 36.1 | 35.9 | 35.8 | 35.7 | 35.5 |
| Maximum Power Current(I) | 8.78 | 8.70 | 8.61 | 8.52 | 8.43 | 8.32 | 8.22 | 8.11 | 7.99 | 7.89 |
| Cell Efficiency | 18.90% | 18.60% | 18.31% | 18.02% | 17.73% | 17.44% | 17.15% | 16.86% | 16.57% | 16.28% |
| Module Efficiency | 16.63% | 16.48% | 16.23% | 15.97% | 15.71% | 15.45% | 15.20% | 14.94% | 14.68% | 14.42% |
| Maximum System Voltage | DC1000V |
| Temperature Coefficient of Voc | -0.27%/°C |
| Temperature Coefficient of Isc | +0.045%/°C |
| Temperaturecoefficient of Pmax | -0.408%/°C |
| Maximum Series Fuse Rating | 15A |
| Number of Cells | 72(6*12) Mono Crystalline silicon, 156*156mm(6 inches) |
| Junction Box | Ip67 rated/with 6 bypass diodes |
| Cable | 4.0mm2
(0.006inches2,symmetrical
lengths(-)1100mm(43.30inches)and(+)1100mm(43.30inches)) |
| Tempered Glass | 3.2mm(0.13inches)tempered glass |
| Cell Encapsulation | EVA(Ethylene-vinyl-Acetate) |
| Back Sheet | composite film |
| Frame | Anodized aluminum alloy |
| Dimension | 1957*992*50mm(77.05*39.06*1.97inches) |
| Maximum Surface Load Capacity | 5400pa |
| Hail | maximun diameter of 25mm with impact speed of 23m-s-1 |
| Temperature Range | -40°C to + 85°C |
| Weight | 23.0kg(50.7bs) |
Application and Advantages:
--- Ideal for hiking, camping, and military use, off-grid solar
panel system, caravan, RV, boat, Green house
solar panel system, solar pump watering system etc.
--- Easy Operation: open up the folding solar panel,face the sun,
battery clips allows for simle connection to
the battery.
--- Pre-installed controller and Pre-wired for 12V battery
charging, you don't have to add extra controller.
With handle, convinient to carry
--- Waterproof IP-65 Rated Junction Box : Advanced water and dust
proof level (complete protection
against environmental particles and low pressure water jets).
Where there is sunlight ,there is power supply!
The foldable solar panel kit with integrated charge controller can
charge a battery directly and also a
usb output to charge mobile phones, tablets and digital camera.
This kit bring mobile solar power for RV,
caravans, motor homes, trucks, golf car, boats as well as all the
outdoor activities..
The foldable solar panel kit with high efficiency solar cell which
can generate maximum power in the
fix area and aluminum frame and supporting bracket, easy to install
to absorb the sunlight, just plug and
play.
