A Grade Solar Panel Photovoltaic Cell / Most Efficient Solar Panels 1480*680*40mm

Yuyao Ollin Photovoltaic Technology Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap A Grade Solar Panel Photovoltaic Cell / Most Efficient Solar Panels 1480*680*40mm from wholesalers

    Buy cheap A Grade Solar Panel Photovoltaic Cell / Most Efficient Solar Panels 1480*680*40mm from wholesalers
    • Buy cheap A Grade Solar Panel Photovoltaic Cell / Most Efficient Solar Panels 1480*680*40mm from wholesalers

    A Grade Solar Panel Photovoltaic Cell / Most Efficient Solar Panels 1480*680*40mm

    Ask Lasest Price
    Brand Name : OLLIN PV
    Model Number : OL-36M-160
    Certification : CE ROSH ISO
    Price : Negotiable
    Supply Ability : 1500UNITS PER WEEK
    Delivery Time : 20DAYS
    • Product Details
    • Company Profile

    A Grade Solar Panel Photovoltaic Cell / Most Efficient Solar Panels 1480*680*40mm

    A grade B grade 1480*680*40mm solar panel 160w mono solar panel solar cell OEM solar panel home


    Features


    Nominal 24V DC for standard output.


    High efficiency.

    Outstanding low-light performance.

    High transmission tempered glass.


    Rugged design to withstands high wind pressure and snow load, easy installation.

    Aesthetic appearance.


    Design to meet unique demand of customer.


    25 year module output warranty.


    Module TypeOLPV130WOLPV140WOLPV150WOLPV160WOLPV165W
    Maximum power130 W140 W150 W160 W165 W
    Max power voltage17.50 V17.70 V17.90 V18.10 V18.20 V
    Max power current7.43 A7.92 A8.38 A8.84 A9.06 A
    Open circuit voltage21.50 V21.70 V21.90 V22.10 V22.30 V
    Short circuit current7.96 A8.49 A9.01 A9.53 A9.74 A
    Module Efficiency13.13%14.14%15.15%16.16%16.67%
    Power Tolerance-0~+5W-0~+5W-0~+5W-0~+5W-0~+5W
    Standard Test Conditions (STC): Irradiance 1000W/m2, Module temperature 25℃? Air Mass (AM)=1.5
    Nominal Operating Cell Temperatur45 ± 2℃
    Temperature coefficients of Isc+0.049% /℃
    Temperature coefficients of Voc-0.340% /℃
    Temperature coefficients of Pmax-0.430% /℃
    Solar CellPoly solar cells 156x156 mm
    Front Cover3.2 mm thick, tempered glass
    Back CoverTPT (Tedlar-PET-Tedlar)
    EncapsulantEVA (ethylene vinyl acetate)
    FrameDouble-layer anodized aluminium alloy
    Junction BoxIP65 rated
    Maximum System VoltageDC1000V (IEC)
    Maximum Series Fuse15 A
    Operating Temperature-40℃~+85℃
    Storage Temperature-40℃~+85℃
    Max. Wind Load / Max. Snow Load2400Pa / 5400Pa
    Application ClassClass A
    Packing configurationCarton.Customers packing requirement is acceptable.

    A Grade Solar Panel Photovoltaic Cell / Most Efficient Solar Panels 1480*680*40mm


    Solar Home System Advantages:


    - CE, ROHS, TUV approved.


    - High conversion efficiency, high-transmission rate.


    - Energy saving, environmental-friendly.


    - Advanced technology, strict quality control system.


    - Easy installation, safe operation, free maintenance.


    - Low MOQ, fast delivery time, long service life.


    - Quality in priority, clients the upmost.


    Solar Home System Applications:


    1. Living house and home building


    2. Office building, factory and warehouse


    3. Shopping mall, venue, stadium and so on


    4. Power station, field operation and some huge engineer construction.



    Product Tags:

    solar power plate



    solar module panel


    Quality A Grade Solar Panel Photovoltaic Cell / Most Efficient Solar Panels 1480*680*40mm for sale
