Tpt Backsheet Residential Silicon Solar Panels 100 Watt 3.2mm Tempered Glass

Ask Lasest Price
Brand Name :	OLLIN PV
Model Number :	OEM
Certification :	CE
Price :	negotiation
Supply Ability :	1800 Piece/Pieces per Week
Delivery Time :	20days

Add to Cart

Product Details
Company Profile

Tpt Backsheet Residential Silicon Solar Panels 100 Watt 3.2mm Tempered Glass

Export high quantity Poly/Mono folding solar panels80W 100W 120W 150W 200W 250W 300W Solar panel

product specification

Item number	OL-100W-P
Power	100W
Solar cell	Polycrystalline 156*104mm
Number of cell	36(4*9)
Moudule size	101067030mm
Optimum operating Voltage(Vmp)	18V
Optimum operating current(Imp)	5.92A
Open-Circuit Voltage(Voc)	21.6V
Open-Circuit Currant(Isc)	5.5A
Module efficiency	13%
Weight	8.5KG
Thickness glass	3.2mm tempered glass
Frame	1.8mm Anodized aluminum alloy
Laminating Material	EVA
Backsheet material	TPT
Junction box	Ip67
Connector	Mc4 connectors with cable
Operating Module Temperature	—40℃to +80℃
Maximum System Voltage	1000V DC
Maximum Series fuse Rating	15A
Power Tolerance	±3%
Irradiance 1000W/m2,Module temperature 25℃,Am=1.5

1.Solar panel power from 3w to 300w according to customers' requirement

2.Solar panel nominl 12/24v DC for standard ourput

3.Aesthetic appearance and rugged design to withstand high wind pressure, hail and snow load

4.Rigorous quality control to meeting the highest international standard

5.Solar panel encapsulated with high transmission low-iron, tempered glass

6. Cells are laminated with TPT and EVA ensuring longer life and maximum performance

7. TPT imported from Krempel, Germany, ensure 25 years output power more than 80%

Product field:

1. Gird-connected power generation system

2. Off-grid power generation system

3. Building-integrated power generation facilities

We have a wild range of successful project all over the world.

We have advanced ,mature and stable supply production line, support your request on solar market

Module Type	OLPV130W	OLPV140W	OLPV150W	OLPV160W	OLPV165W

Maximum power	130 W	140 W	150 W	160 W	165 W
Max power voltage	17.50 V	17.70 V	17.90 V	18.10 V	18.20 V
Max power current	7.43 A	7.92 A	8.38 A	8.84 A	9.06 A
Open circuit voltage	21.50 V	21.70 V	21.90 V	22.10 V	22.30 V
Short circuit current	7.96 A	8.49 A	9.01 A	9.53 A	9.74 A
Module Efficiency	13.13%	14.14%	15.15%	16.16%	16.67%
Power Tolerance	-0~+5W	-0~+5W	-0~+5W	-0~+5W	-0~+5W
Standard Test Conditions (STC): Irradiance 1000W/m2, Module temperature 25℃? Air Mass (AM)=1.5
Nominal Operating Cell Temperatur			45 ± 2℃
Temperature coefficients of Isc			+0.049% /℃
Temperature coefficients of Voc			-0.340% /℃
Temperature coefficients of Pmax			-0.430% /℃
Solar Cell			Poly solar cells 156x156 mm
Front Cover			3.2 mm thick, tempered glass
Back Cover			TPT (Tedlar-PET-Tedlar)
Encapsulant			EVA (ethylene vinyl acetate)
Frame			Double-layer anodized aluminium alloy
Junction Box			IP65 rated
Maximum System Voltage			DC1000V (IEC)
Maximum Series Fuse			15 A
Operating Temperature			-40℃~+85℃
Storage Temperature			-40℃~+85℃
Max. Wind Load / Max. Snow Load			2400Pa / 5400Pa
Application Class			Class A
Packing configuration			Carton.Customers packing requirement is acceptable.

FAQ

Q1 Are you a factory or trading company?

A Yes, we are factory, supplying OEM/ODM service.

Q2 Can you accept OEM service?

A Yes, we can. Qty is not the only standard , more qty, less cost.

Q3 How about your after sales-service?

A 1.Guarantee time: one year, but solar panel 10 years

Q4 How about your payment terms?

A We accept T/T, LC

Q5 What certification do you have?

A 1.CE, 2.According to your need , do the certification or report , if you have a big order.

Q6 How many day about delivery time?

A 1.Sample delivered in 3-5 days.

2.Order delivered in 15-20 days.

Q7 Which port shipping goods?

Ningbo port/ shanghai port/yiwu port
